1. Waterproof bracket BIPV
Through the unique waterproof and diversion design of the bracket, the conventional photovoltaic modules are replaced or covered with roof building materials. This photovoltaic roof installation method is called BIPV waterproof bracket solution. If the roof color steel tile is directly replaced, another thermal insulation and fireproof layer must be laid. This is a BIPV solution with more than 80% of applications at this stage.
2. Planar photovoltaic tile BIPV
The module frame is used to make a lock structure, and then cooperate with the waterproof and diversion design to replace or cover the roof building materials. This photovoltaic roof installation method is a flat photovoltaic tile BIPV solution. If you directly replace the roof color steel tile, you also need to lay additional insulation and fire protection layers. This is the most reliable BIPV technology solution for waterproofing principle at present.
3. Metal backplane photovoltaic BIPV
By making the frame of the galvanized aluminum alloy back panel into a lock structure to replace or cover the roof building materials, this photovoltaic roof installation method is a metal back panel photovoltaic BIPV solution. If you want to directly replace the roof color steel tile, you only need to lay an additional thermal insulation layer, and you do not need to add a fireproof layer. This is the BIPV technical solution with the highest fire protection capability at this stage.
4. Flexible photovoltaic BIPV
Flexible photovoltaic BIPV uses polymer materials to replace the glass of traditional photovoltaic modules, so it has the characteristics of being thinner and softer, and it is easier to bend according to the shape of the building. If you want to directly replace the roof color steel tile, you need to add a fireproof layer, a thermal insulation layer and a waterproof structure design. This is the most gentle BIPV technology solution at this stage.
With the continuous advancement of technology, BIPV will develop into the mainstream of distributed rooftop photovoltaics in the future. The four BIPV technology routes introduced above are the main representatives of future market development.
Xiamen HQ Mount has 15 years of experience in the design and manufacture of solar mounts. In recent years, our mounts have also covered the field of BIPV. In addition, we also have mature solar ground mounts, solar roof mounts, solar aluminum carports, carbon steel solar carport and other products, to achieve a stable sales of 1GW per year, if your project needs to purchase solar support machine accessories, please contact us!
